不銹鋼素管

  富好生產不銹鋼管產品符合汽、機車排氣系統使用規格尺寸,品質均符合車廠要求嚴謹的加工過程,如:彎管、擴口、縮口…等。





產品規格尺寸


0.6
0.8
1.0
1.2
1.5
2.0
INCH
MM
10 ● ● ● ● ●
12.0** ● ● ● ● ●
1/2” 12.7 ● ● ● ● ●
5/8” 15.9 ● ● ● ● ●
17.3 ● ● ● ● ●
19.1 ● ● ● ● ●
20 ● ● ● ● ●
21 ● ● ● ● ●
21.7 ● ● ● ● ●
7/8” 22.2** ● ● ● ● ● ●
1” 25.4** ● ● ● ● ● ●
26 ● ● ● ● ● ●
27.5 ● ● ● ● ● ●
1-1/8” 28.6** ● ● ● ● ● ●
30.0** ● ● ● ● ● ●
1-1/4” 31.8** ● ● ● ● ● ●
33 ● ● ● ● ● ●
34 ● ● ● ● ● ●
1-3/8” 35 ● ● ● ● ● ●
36 ● ● ● ● ● ●
37 ● ● ● ● ● ●
1-1/2” 38.1** ● ● ● ● ● ●
1-5/8” 41.3 ● ● ● ● ● ●
42.0** ● ● ● ● ● ●
42.7** ● ● ● ● ● ●
43 ● ● ● ● ● ●
1-3/4” 44.5** ● ● ● ● ● ●
45.0** ● ● ● ● ● ●
45.6 ● ● ● ● ● ●
46.2 ● ● ● ● ● ●
47.6** ● ● ● ● ● ●
48.6** ● ● ● ● ● ●
49 ● ● ● ● ● ●
50.0** ● ● ● ● ● ●
2” 50.8** ● ● ● ● ● ●
51.6 ● ● ● ● ● ●
52 ● ● ● ● ● ●
2-1/8” 54.0** ● ● ● ● ● ●
2-1/4” 57.0** ● ● ● ● ●
58 ● ● ● ● ●
60.0** ● ● ● ● ●
60.5** ● ● ● ● ●
2-1/2” 63.5** ● ● ● ●
64 ● ● ● ●
65 ● ● ● ●
68 ● ● ● ●
70 ● ● ● ●
75 ● ● ● ●
3” 76.2 ● ● ● ●
Ps: 管件長度: 20-6000 mm
ERW 尺寸: 打**項目
